Aerator

TECHNICAL SPECIFICATIONS
Tines . . . . . . . . . . . . . . . 0.75 in. (19 mm) diameter coring type formed
from 0.08 in. (2 mm) hollow, hardened alloy steel;
Number of Tines . . . . . . . . . . . . . . . . . . . . . . . . . . . 30 tines per aerator
Coring Depth . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Up to 2.75 in. (70 mm)
Core Diameter……………………………. 0.75 in. (19 mm)
Aerating Width . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19 in. (483 mm)
Aeration Pattern . . . . . . . . . . . . . . . . . 3.75 in. x 7 in. (95 mm x 178 mm)
Holes per Sq Ft . . . . . . . . . . . . . . . . . . . . . . . . . . . . . up to 9 sq ft
Productivity . . . . . . . . . . . . Aerates up to 29,000 sq ft/hr
at 3.5 mph (4.83 kph)

DIMENSIONS
Weight: Wet w/o Weights . . . . . . . . . . . . . . . . . . . . . . . . . . 214 lb
Weight: Wet w/Weights . . . . . . . . . . . . . . . . . . . . . . . . . . 255 lb
Weight: Wet w/Weights and Water in Drum……….298 lb
Width . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28 in.
Length . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53.5 in.
Height . . . . . . . . . 48.8 in.; 30 in. w/handle folded

POWER
Honda®
Engine Model . . . . . . . . . . . . . . . . . 4-cycle Honda® GX120; recoil start;
on/off switch; low-oil alert
Displacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7.2 cu in.
Fuel Capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0.53 gal.
Oil Capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0.59 qt
